The SQ-Rack is supplied with 2x 4U rack ears which can be fitted to the unit in multiple ways using the supplied fixings. This enables the unit to be used freestanding, fixed to a flat surface, or to be mounted in different orientations and angles in a standard 19” rack.
Left and right rack ear orientation
Either one, or both rack ears include an arrow to show the intended upward direction when fitting in a rack.
This mounts the SQ-Rack a few millimetres higher in the rack and is only important when rack mounting with the feet already fitted, directly above another unit.
Attaching the ears to the SQ-Rack
• Hold the first ear to the unit in roughly the position it will be attached (see Mounting Options)
• Align and fit the centre fixing, but do not fully tighten
• Rotate the ear to align the other two fixing holes
• Fit the outer fixings and tighten fully
• Tighten the centre fixing
• Repeat the process for the second ear, matching orientation and angle
Freestanding (desktop stand) use
When using the rack ears affixed to the bottom edge of the unit for freestanding use, the 4 ‘push fit’ feet supplied with the SQ-Rack can be fitted to the small holes in the rack ears instead of the unit itself.
When fitted for freestanding use, ears can be angled outward (as when rack mounting) or angled inward (under the unit).
Mounting options
Front, rear or freestanding options are decided by which fixing holes on the SQ-Rack are used.
Flush or recessed positions are available when mounting straight (0°), with the rack strip or surface parallel to the front, rear or base of the SQ-Rack.
In the front recessed position, the tops of rotary controls are parallel with the rack strip.
The entire unit can be angled by ±7.5° or ±15° by turning the ears about the centre fixing. Note that when mounting at an angle in a rack, more that 4U space may be required.
